The R911308421 (HCS03.1E-W0150-A-05-NNBV), from Bosch Rexroth’s IndraDrive Electric Drives and Controls category, is a versatile electrical part suitable for various machinery types, including machine tools, paper processing and printing machines, mounting and handling systems, and food and packaging machines. This part should only be used as expressly authorized by Rexroth, accompanying strict adherence to safety instructions. The device requires discharge in the event of overvoltage exceeding 33 Volts, achieved with 24 Volt equipment designed to reduce overvoltage down to acceptable values, or via overvoltage limiters installed in the control cabinet. This rule also applies to lines running parallel to main cables and power cables capable of absorbing overvoltage through capacitive and inductive coupling. Faulty drive movements depend on the type of control and operation status, highlighting the importance of following manufacturer guidelines. After the installation of R911308421 (HCS03.1E-W0150-A-05-NNBV), all parts should be reconnected and fully assembled before conducting equipment testing.
Specs
Unsuitable Applications: Non-authorized purposes Overvoltage Discharge: Must happen in case of excess over 33 V Dependent Factors for Faulty Movements: Control type, State of operation
